Manual filler
This volumetric filling machine can fill a variety of liquid products onto a bottle or container. Often considered an entry-level machine due to its compact size and ease of use, this machine offers one of the most accurate, simple, and effective liquid-filling solutions in the market. It is often used to fill containers with beverages, juices, sauces, salad dressings, cosmetic products, sanitizers, and much more.
Technical information
Manual filler
This volumetric filling machine can fill a variety of liquid products onto a bottle or container. Often considered an entry-level machine due to its compact size and ease of use, this machine offers one of the most accurate, simple, and effective liquid-filling solutions in the market. It is often used to fill containers with beverages, juices, sauces, salad dressings, cosmetic products, sanitizers, and much more.
Features:
EASY TO USE: Intuitive operation and simple machine adjustments for an easy-going and uncomplicated user experience.
AVOID OVER / UNDER POURING: Allows only an exact and predetermined amount of product to flow from the supply system into the bottle or container.
EASY SANITATION: Disassemble and reassemble the machine's pieces with ease and enjoy hassle-free cleaning.
STAINLESS STEEL CONSTRUCTION: Strong, durable, easy to sanitize, and resistant to corrosion.
TABLETOP DESIGN: Easy to move, convenient size that takes up little space but yields exceptional results.
ANTI-DRIP VALVE: Enjoy high accuracy and no spillage in your filling line.
FOOD SAFE DESIGN: Based on heavy-duty stainless steel frames with all contact parts made of food grade materials.
QUICK CHANGEOVER: Set different filling volumes within seconds with the simple use of a turn-knob.
MAXIMIZED PRODUCTION: Allows you to fill and deposit your products at much higher speeds.
Specification
Model no : MF-50
Material: Stainless Steel
Filling Range: 0.17-1.7 oz / 5-50 ml (adjustable)
Capacity of Hopper: 22 lbs / 10 kg
Height Range: 7.87 in / 20 cm
Bottle Diameter Range: 0.12-0.6 in / 3-15 mm
Filling Accuracy: ±1%
Speed: 20-30 times/min
Machine Size: 10.6 x 10.6 x 27.5 in / 27 x 27 x 71 cm
Packing Size: 13.4 x 13.4 x 31.1 in / 34 x 34 x 79 cm
Net Weight: 28.5 lbs / 13 kg
Gross Weight: 37.5 lbs / 17 kg
Filling Material: Paste liquid with good fluidity(cosmetic, cream, shampoo)
Wire Thickness of Spring: 2 mm
Spring Length: 110 mm
Spring Diameter: 15.7 mm
